Overview:
Introducing the Orko Model X Wheel Guide! In this comprehensive guide, we dive into everything you need to know about the wheels for your Tesla Model X. From stock options to aftermarket upgrades, we cover all the details on the best wheel choices for your Model X.
You'll learn about the latest wheel trends, different wheel finishes and styles, as well as how to choose the right wheel size for your Model X. We also cover important information such as compatibility, performance, and cost to help you make an informed decision. Whether you're looking for a subtle change or a complete overhaul, our Model X Wheel Guide has you covered.
So, whether you're a seasoned Model X owner or just starting your research, be sure to check out our Model X Wheel Guide to enhance the look and performance of your Tesla. Your Tesla, Redesigned.
OEM Wheel Options: (2016-2020)
1. 19" Tesla Model X Cyclone Wheel
Tesla sold this wheel as a part of the winter wheel and tire package for the Model X. The Tesla Model X Cyclone Wheel was only available in silver finish and weighs 29 lbs.
Size: 19x8.5"
Offset: +35
Bolt pattern: 5x120
Center Bore (CB): 64.1mm
OEM Tire Specs: 265/50/19
Option Cost: $4400 USD
This wheel was distributed by Tesla as an option or as a part of a wheel and tire package in the Tesla Store. Weighing in at 34 lbs for the front, and 35 lbs for the rear, this wheel was only available in silver. Due to the difference in wheel width, this set is staggered from the factory.Size: 20x9" front, 20x10" rear
Offset: +35
Bolt pattern: 5x120
Center Bore (CB): 64.1mm
OEM Tire Specs: 265/45/20 front, 275/45/20 rear
Option Cost: $2500 USD option, $5500 USD in wheel and tire package
This wheel was distributed by Tesla as a standard no-charge option on all 2016-2020 Model X. The Slipstream weighs 32 lbs front, and 33.2 lbs rear. Due to the difference in wheel width, this set is staggered from the factory. The available finishes were Sonic Carbon and silver.
Size: 20x9" front, 20x10" rear
Offset: +35
Bolt pattern: 5x120
Center Bore (CB): 64.1mm
OEM Tire Specs: 265/45/20 front, 275/45/20 rear
Option Cost: Included*
This wheel was distributed by Tesla as a wheel upgrade option. Weighing in at 37.6 lbs front, and 40.4 lbs rear. There were two finish options produced. Silver or Onyx Black. Due to the difference in wheel width, this set is staggered from the factory. Size: 22x9" front, 22x10" rear
Offset: +35
Bolt pattern: 5x120
Center Bore (CB): 64.1mm
OEM Tire Specs: 265/35/22 front, 285/35/22 rear
Option Cost: $4400 USD
OEM Wheel Options: (2021-Present)
This wheel was the standard wheel included on all Long Rang and Plaid Tesla Model X. Only available in Tesla's gray finish. The wheels weigh in at 32 lbs for the front and 33.2 lbs for the rear. Due to the difference in wheel width, this set is staggered from the factory. Size: 20x9" Front, 20x10" Rear
Offset: +40 Front, +35 Rear
Bolt pattern: 5x120
Center Bore (CB): 64.1mm
OEM Tire Specs: 265/45/20 Front, 275/45/20 Rear
Option Cost: Included*
This wheel is the only optional wheel upgrade for this generation Model X. The front weighs in at 36.55 lbs for the front and 41.6 lbs for the rear. Due to the difference in wheel width, this set is staggered from the factory. Only one finish (Gunpowder).Size: 22x9" Front, 22x10" Rear
Offset: +35 Front
Bolt pattern: 5x120
Center Bore (CB): 64.1mm
OEM Tire Specs: 265/35/22 Front, 285/35/22 Rear
Option Cost: $5500 USD
Orko Recommended Wheels/Specs:
1. Orko SV1 - Available in Gloss Black, Satin Gunmetal, or Gloss Silver
The Orko SV1 is our most popular wheel for Model S, 3, and X owners. Sporting a clean, modern, and aggressive look, you can't go wrong with these wheels. The SV1 is a strong forged monoblock wheel allowing for decreased unsprung weight, and a wheel that will hold up durability-wise. Due to the weight decrease, you can expect more range than any factory Tesla wheel.
2. Orko CB1 - Available in Gloss Black, Satin Gunmetal, or Gloss Silver
The Orko CB1 is another one of our most popular wheels for Model S, 3, X, and Y owners. Sporting a clean, modern, and classy look, you can't go wrong with these wheels. The CB1 is a strong forged monoblock wheel allowing for decreased unsprung weight, and a wheel that will hold up durability-wise. Similar to the SV1, due to the weight decrease, you can expect more range than any factory Tesla wheel.
See wheel configuration options below:
Option 1:
Size: 22x9" Front, 22x10" Rear
Offset: +25
Bolt pattern: 5x120
Center Bore (CB): 64.1mm
Recommended Tire Specs: 265/35/22 Front, 285/35/22 Rear (OEM Turbine tire size)
